Quick Coupling ISO B Socket 3/8 S/Steel Viton BSP | Action Sealtite

QuickBreak® ISO B Socket 3/8" 303 S/S Viton Seal BSP Thread

Customer Orders Available

Call on +44 (0)1235 512500

Product Code: QDB-S038SS-RPV
1+ £37.45

Technical Specification

Size 3/8"
Thread Type BSPP
Connection Female Coupler by Female Thread
Material Stainless Steel 303
Pressure 280Bar / 4100PSI
Seal Type Viton/FKM
Series Part ISO B

Product Description

Technical Information

When disconnecting this quick coupling, the socket and plug valves seal instantly, automatically shutting off fluid flow to prevent leakage. On connection the socket and plug valves push together, opening to permit free flow of fluid. O-ring in the socket seals the connection preventing any leakage.

Special Features

Branded with our own QuickBreak® logo for traceability | Multi-purpose quick coupling


Applications include general in-plant use, High-pressure hydraulic circuits, Connection of hydraulic pumps valves and quick tool change, Aluminium die casting, Test benches, Plastic industry tool changing and mobile equipment, or anywhere where a quick coupling system is vital to work-flow.
